Our floor wells are domestic, stainless steel wells of high quality and durability.
A specially shaped sewer pipe has been used to maximise the height of the sewer outlet. The well is equipped with a fixed water trap with a rubber stopper for easy cleaning. The well is fitted with the necessary fitting at the factory to ensure that the well is watertight even between the floor material and the well. The target cover supplied with the well can also be supplied as a pump trolley
or forklift resistant cover.
The well can be connected directly to the floor tank at the factory, offering flexibility for different installation options. A septic tank is available as an option
If required, a riser and a DN32 or DN50 branch are available for the manhole. For more information on these, please contact sales.
| Templates | Departure from | Flooring material | Plumbing number | Flow rate |
|---|---|---|---|---|
| 9050/1 | DN75 | Carpet | 3305184 | 0,93 l/s |
| 9050/3X | DN75 | Tile | 3305185 | 0,93 l/s |
| 9050/4 | DN75 | Mass | 3305186 | 0,93 l/s |
| Templates | Departure from | Flooring material | Plumbing number | Flow rate |
|---|---|---|---|---|
| 9051/1 | DN110 | Carpet | 3305188 | 1,63 l/s |
| 9051/3X | DN110 | Tile | 3305189 | 1,63 l/s |
| 9051/4 | DN110 | Mass | 3305190 | 1,63 l/s |
